Viewsonic ViewBoard® 65" 4K Interactive Display

Panel Size:

65"

Panel Type:

TFT LCD Module with DLED Backlight.

Display Area (mm):

1428.48(H)x 803.52 (V) (64.5” diagonal)

Aspect Ratio:

16:9

Resolution:

UHD 3840x2160(Pixels)

Colors:

1.07B colors (8bit+FRC)

Brightness:

350 nits (typ.)

Contrast Ratio:

4000:1

Response Time:

6.5ms

Viewing Angles:

H=178, V=178typ.

Backlight Life:

30,000 Hours (Min)

Surface Treatment:

Hardness: 9H Anti-glare coating

Orientation:

Landscape

Processor:

ARM quad-core Cortex-A55

RAM:

4GB DDR4

Storage:

32 GB

Type/ Tech:

Ultra Fine Touch Technology

Touch Point:

20 points touch, 2 points writing

HDMI:

HDMI 2.0 x2 (3840x2160 @60Hz)

RGB / VGA:

x1

Audio:

x1

RS232:

x1

OPS:

x1 (Optional Intel Standard OPS)

WiFi:

x1 (Optional VB-WIFI-002/VB-WIFI-004)

Audio:

x1

RJ45:

x1

Type A:

USB2.0 Front x2; Side x2

Type B:

x1 for HDMI/VGA touch

10W x 2

Yes

Android 9

Basic Annotation Software:

myViewBoard Whiteboard

Pro Annotation Software:

myViewBoard Whiteboard for Windows (Embedded in optional Windows Slot-in PC)

Wireless Presentation:

myViewBoard Display & ViewBoard Cast​

All-in-one USB port:

(combine slot-in PC/Android/HDMI USB port) Front “SmartPort™ USB” to all channels.

Simple LAN sharing between IFP and slot-in device:

10/100M for Android & Slot-in PC

Light Sensor:

Yes

Voltage:

162V-264V +/- 10%

Consumption:

On: 175W(typ.)
Off: ≤ 0.5W\

Wall Mount (VESA® ):

600*400

Temperature (º C):

0°C to 40°C

Humidity:

10% ~ 90% RH non-condensing

Physical (inch / mm):

1489×897×87 mm / 58.6x35.3x3.4 in

Packaging (inch / mm):

1628×208×1005 mm / 64x8.2x39.5 in

Net (lb / kg):

38.3kg/84.4lb

Gross (lb / kg):

46.0kg/101.4lb

EMC/CE , CB/LVD, GOST-R / EAC, FAC, RCM, BIS, ECAS, LBL (Low Blue Light Certification), RoHS, REACH, SCIP, WEEE, TPCH, Packing waste, CA65, Green BOM, ErP-Eco

1. Power cord / 2.Remote control with AAA battery / 3.USB touch cable / 4. Touch pen x 2 / 5. Quick Start Guide + Compliance statement /  6. RS232 adapter / 7. Screw x 4 ( wall mount 4) / 8. HDMI cable / 9. Clamp x5 / 10. Camera plate x1

VPC12-WPO/VPC25/VPC2C/VPC27 series
